BYMK-180S concrete pile cutter hydraulic round pile breaker

FOB Reference Price:Get Latest Price
US $8,000-35,200 / Sets | 1 Set/Sets Crane parts concrete block breaker/pile cutter (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Jiangsu, China (Mainland)
Brand Name:
BEIYI
Model Number:
MK180S
Place of Origin::
Jiangsu China(Mainland)
Brand Name::
BEIYI
Type::
concrete block breaker
Color::
As customer's requested
Packing method::
Wooden box packing
Products Capacity::
20 sets/month
Product Material::
No.45 steel
Port::
Shanghai
After-service::
Offering after-sales support services
Condition::
New
Supply Ability
Supply Ability:
50 Set/Sets per Month BYMK-180S concrete pile cutter hydraulic round pile breaker
Packaging & Delivery
Packaging Details
Concrete block breaker packing with wooden box
Port
shanghai port or as you request
Lead Time :
Shipped in 7 days after payment
Video Description

BYMK-180S concrete pile cutter hydraulic round pile breaker

 Product Description

BEIYI MACHINERY Hydraulic pile breaker can break such like cast-in-place piles, precast piles etc. It can be divided into round and square by the pile shape. Our hydraulic pile breaker is widely used in high-speed railway bridges and civil building pile foundation engineering. Normally hydraulic round pile breaker can break pile diameter from 600-2200mm and hydraulic square pile breaker is suitable for square piles from 300-650mm. Our machine can meet the requirements of all kinds of large-scale infrastructure construction



* BEIYI MACHINERY Hydraulic pile breaker is the most advanced and can achieve high efficiency, low noise in pile broken.
* It has the advanced modularization and break different diameter pile by different number of modular combination.



* It has high cost performance, low operating cost and its cost performance is nearly the same with the foreign products.



* It operates easily and don’t need any professional skill, besides, it operates very safely.



* It can be connected to a variety of engineering machinery to make achieve of products’ commonality and economical efficiency. It also can be hanged in the excavators, cranes and telescopic arm, etc.



* High life design can bring you the best benefits.







Hydraulic Pile Breaker Working Principle



 BEIYI MACHINERY hydraulic pile breaker offer its several cylinders oil pressure through power source and cylinder directly drive the chisels and squeeze the pile body at the same time to break the pile. It operates easily and has high effiency, low noise, low cost in the pile cutting construction process, which is suitable for pile group in construction engineering. Hydraulic pile breaker machine adopts highly modular combinations and connect modules through axis pins. It can break piles in certain ranges of diameter by different number of modules combination.

Product parameters

Module

Number

 489101112131415161718

Combination

total weight

kg

Remark Need

to add the

connections

1600

26242952328036083936426445924920524855765904

Pile diameter

range

mm200-800600-800800-10001000-11501150-13001300-15001500-16501650-18001460-19701620-22002200-23602360-2500

Hydraulic

excavator

T20-30T30-40THydraulic system/pump station
Max Thrust300KNMax Cylinder required20L/minMachinery Tonnage≥20t

Max Cylinder

Trip

300mmChisel diameter110mmSingle module weight328kg

Max Cylinder

Pressure

30MPaMax Hoist Capacity≤500mmSingle module size885*780*340mm



Main products





Trade show



Company Information

Wuxi Beiyi Excavator Parts Factory is located in Wuxi famous industrial town Luoshe town. Our factory was founded in the year of 2011; we are one of the most professional manufacturer in China engaged in developing, producing and selling engineering machinery and oil cylinder accessories.



Our main products are hydraulic pile breaker, hydraulic shears, H-beam pile drawing machine, hydraulic earth drill, tree spade, mini crawler loader and excavator spare parts.



Beiyi Machinery will keep growing and try to become the leading factory in our industry. We warmly welcome you to visit our factory!

Our Team



Packaging & Shipping

 We packed with standard wooden box, single module packed in individual small box and several box bundled into pallet.



Our Services

Wuxi Beiyi Excavator Spare Parts Factory warmly welcome our customers' inquiry about all kinds of pilling foundation machines and construction products.



We can offer professional technical supports and good after sale service for your orders.



We have a stronger R&D team who can develop and produce the special machines according to your requests.



FAQ



1. Q:How to chose the modules?

    A: Please kindly advise your pile diameter, your pile concrete grade, and your project situation, we will help you to decide the numbers of the modules.



2. Q: Is your pile breaker dangerous for work?

    A: Our machine operate contact-free and there is no impact force on the piles, so our machine is not dangerous for work.



3. Q:Is your module changeable or fixed?

    A:Our module round pile breaker is changeable, you can combine freely according to your different pile diameter, the modules can be assembled and disassembled easily and conveniently.
We also can custom made for your small round piles which is fixed with 5 modules.



4. Q:Do you offer after-sale service?

    A: Yes, we will offer you machine operation instructions. 6 months of warranty time will offer to our customer dating from the receipt day. Besides, we will offer some spare parts for free and life long technical instruction.



5. Q:Is your machine working with noisy?

    A: We got CE approved and our machine working with low noisy which can meet environmental protection.
