Hydraulic pile driver is using its high frequency vibration to vibrate pile body with high acceleration to pass the vertical vibration of mechanical produce to pile which leading to changes in the soil structure around the pile, strength decrease. Soil around the piles become liquefaction to reduce frictional resistance between side of the pile and the soil. Then using the excavator down force, vibrating pile hammer and pile body weight to sink pile into the soil. When extracting piles, in the condition of vibration to pull out the pile by using excavator lift force. Excitation force needed by pile driving machinery are comprehensive determined by site soil, soil condition, moisture content and type of pile, construction.
--Easy operation --Flexible control --Silence operation --Easy maintenance --Precision design --Reliable performance --Quick speed --Save time
1.Hydraulic motor driven turntable The latest inner gear design, effectively avoid the dirt and collision, gear is changeable, stable and durable, very reliable!
2.Ventage Ensure the gear box pressure balance,stable heat removal.
3.Adopts highly efficient imported damping rubber block. Stable quality, long service life!
4.Adopts original imported hydraulic motor. Double efficiency, superior quality!
5.Powerful hydraulic cylinder,Super durable tooth piece. Strong and never loose clip mouth is the first condition of safety construction. We specially add the double pressure protection device, firmly lock the system pressure and then ensure the stability and reliability of the clamping plate pile.
6.Precision oil system Special designed according to driver functions and features and effectively increase the use of the pile driver efficiency.
7.Well designed circuit control box Adopts safety and reliable spaceflight joint, sufficient protects the stability of the circuit. The whole circuit system, not only easy to install but also maintenance is convenient.
8.Adopts original imported control handle Multifunctional integration, beautiful and practical, easy reliable installation , high reliability.
9.Detachable lazy arm and flip axis Accurate matching with small gap, easy maintenance with no worries.
Hydraulic pile driver working principle and engineering application scope
BEIYI Machinery. V series high frequency hydraulic vibratory pile driver is using vibrating pile sinking to drive or extract piles. It is especially suitable for municipal, bridges,cofferdam, building foundation etc. such short pile projects.
Pile Driver Application
The efficient of vibration pile method is higher than other methods. It is mainly are fit for driving and extracting sheet piles, I-steel piles, Cement square pile,cylinder pile, larsen piles in various shapes. This pile driving method is the most suitable for working in sand and poorer effect in the clay which must select higher power model machines.
The whole body includes
1. Vibratory hammer
4. Handle and Control box, etc.
Pile Hammer How to Work?
Vibrating pile hammer is using its high frequency vibration to vibrate pile body with high acceleration to pass the vertical vibration of mechanical produce to pile which leading to changes in the soil structure around the pile, strength decrease. Soil around the piles become liquefaction to reduce frictional resistance between side of the pile and the soil. Then using the excavator down force, vibrating pile hammer and pile body weight to sink pile into the soil. When extracting piles, in the condition of vibration to pull out the pile by using excavator lift force. Excitation force needed by pile driving machinery are comprehensive determined by site soil, soil condition, moisture content and type of pile, construction.
Hydraulic pile driver operating principle
1. V series high frequency hydraulic vibratory pile driver internally installed two eccentric shaft. It adopts hydraulic motor to drive and produce high-speed revolution and vertical vibration force. Through the damping rubber block to maintain a certain amplitude to cope with various types of soil and pile driving.
2.Exciting force is proportional to the eccentric shaft size and the vibration times square. BEIYI eccentric shafts are all made after a detailed calculation and test which can combine strong vibration force and material properties, not only can meet the needsof the work but also guarantee the mechanical reliability.
Weight of main body
of oil system
Flow Demand for
Hydraulic oil system
Max pile length
Please click products below to see more details
WuXi BeiYi Excavator Parts Factory is a professional high tech enterprise based in Wu xi with an area of 5000 square meters workshop. It is established in 2000 and has convenient transportation access. We are fully committed to producing technologically advanced excavator parts and we have our own technical engineering research center and pile driving machinery engineering center. Our core team is composed of senior staff in the industry and has the international advanced R&D system and technical level. We are concerned on research and development to ensure that we can provide our customers with top quality and the innovative products.
We emphasize development and continually introduce new products into the market every year. Our products are sold well in domestic and international markets, such as America which are highly appraised by the clients. We pursue the management with the tenet of "Attention to detail, Keep improving, Today completed the matter today ", and will insist on "concentration, creation, achievement, value" as our company philosophy.
We will work hard to become the leader of the small and medium-sized pile driving machinery company. We appreciate you to contact us for more information and look forward to working with you.
Packaging & Shipping
We packed with standard wooden box or as you request.
1. Q:How to chose the suitable model? A: Please kindly advise your excavator weight or model, then we will help you to decide the suitable model.
2. Q: Is your vibro driver dangerous for work? A: Our machine operate contact-free and there is no impact force on the drill rod, so our machine is not dangerous for work.
3. Q:Is your size can be custome made? A:Yes, we can custom made according to your requests.
4. Q:Do you offer after-sale service? A: Yes, we will offer you machine operation instructions. 6 months of warranty time for the motor will be offered to our customer dating from the receipt day. Besides, we will offer life long technical instruction.
5.Q:How To Order: 1. Please tell us the model with quantity and other requirement which you needed. 2. We issue the Proforma Invoice to you after confirmed the price and other details. 3. We arrange the order production upon receipt of confirmed PI and your deposit or original L/C. 4. After the goods is ready to ship, we will inform you the shipment date and other informations by email at the same time. 5. We will help to track your goods until you receive them safely.
